Heidenhain UE 230 ID: 329037-01 “Rigenerato”

Di wp_6386993 / Aprile 10, 2024

Heidenhain UE 230 ID: 329037-01 “Rigenerato”

UE 230 ID: 329037-01

COD: Heidenhain UE 230 ID: 329037-01 "Rigenerato" Categoria: Heidenhain Tag: 329037-01, azionamento, cnc, Heidenhain, UE230

Descrizione
Informazioni aggiuntive

UE 230
Compact inverter
Rated current 5 kHz: 2 x 7.5A-axes and
31A-spindle
Max. current at 5 kHz: 2x 15A and 46A
Rated power: 20 kW
Power S6-40%: 28 kW
Peak power: 28kW
DC-link voltage: 565 V
Low-voltage power supply
unit: 80 W
Type of heat removal: internal
Braking resistor: external
Connection for holding
brakes: no connection
Module width: 200.00 mm
